• British-Standard-Sprockets
1 - 25 de 26 | Resultados por página | Visualizar | Unidade de medida
1 2
Solicitação de cotação/informações Comparar itens Pesquisar por especificação

Nº. do item

Nº. de dentes

d - Plane Bore

Max. Plain Bore

Style

Wt. LBS

N/A 8 N/A 0.315 pol. N/A 0.354 pol. N/A S N/A 0.07 lb
N/A 9 N/A 0.315 pol. N/A 0.433 pol. N/A S N/A 0.09 lb
N/A 10 N/A 0.315 pol. N/A 0.472 pol. N/A S N/A 0.13 lb
N/A 11 N/A 0.315 pol. N/A 0.551 pol. N/A S N/A 0.20 lb
N/A 12 N/A 0.315 pol. N/A 0.630 pol. N/A S N/A 0.22 lb
N/A 13 N/A 0.394 pol. N/A 0.709 pol. N/A S N/A 0.24 lb
N/A 14 N/A 0.394 pol. N/A 0.748 pol. N/A S N/A 0.26 lb
N/A 15 N/A 0.394 pol. N/A 0.787 pol. N/A S N/A 0.31 lb
N/A 16 N/A 0.394 pol. N/A 0.866 pol. N/A S N/A 0.40 lb
N/A 17 N/A 0.394 pol. N/A 0.984 pol. N/A S N/A 0.44 lb
N/A 18 N/A 0.394 pol. N/A 0.984 pol. N/A S N/A 0.51 lb
N/A 19 N/A 0.394 pol. N/A 1.102 pol. N/A S N/A 0.55 lb
N/A 20 N/A 0.394 pol. N/A 1.181 pol. N/A S N/A 0.68 lb
N/A 21 N/A 0.472 pol. N/A 1.181 pol. N/A S N/A 0.79 lb
N/A 22 N/A 0.472 pol. N/A 1.260 pol. N/A S N/A 0.82 lb
N/A 23 N/A 0.472 pol. N/A 1.260 pol. N/A S N/A 0.86 lb
N/A 24 N/A 0.472 pol. N/A 1.260 pol. N/A S N/A 0.88 lb
N/A 25 N/A 0.472 pol. N/A 1.378 pol. N/A S N/A 0.90 lb
N/A 26 N/A 0.472 pol. N/A 1.496 pol. N/A S N/A 0.93 lb
N/A 27 N/A 0.472 pol. N/A 1.496 pol. N/A S N/A 0.97 lb
N/A 28 N/A 0.472 pol. N/A 1.496 pol. N/A S N/A 0.99 lb
N/A 29 N/A 0.472 pol. N/A 1.496 pol. N/A S N/A 1.04 lb
N/A 35 N/A 0.551 pol. N/A 1.575 pol. N/A S N/A 1.50 lb
N/A 40 N/A 0.630 pol. N/A 1.772 pol. N/A S N/A 1.79 lb
N/A 45 N/A 0.630 pol. N/A 1.772 pol. N/A S N/A 2.01 lb
