Dimensions shown are nominal. Obtain certified prints for design and construction.
To locate compatible sprockets for your chain, refer to the Product Cross-Reference in Section D.

Note: Dimensions are subject to change. Contact U.S. Tsubaki to obtain certified prints for design and construction.
1 - 25 of 83 | Results Per Page | View | Unit of Measure
1 2 3 4
Request for Quote/Information Compare Items Search by Specification

Item #

Pitch

G - Pin Diameter

D - Roller Diameter

E - Inside Width

T - Sidebar Thickness

H - Sidebar Height

Average Ultimate Strength

Max. Work Load

N/A 1.654 in N/A 0.440 in N/A 0.880 in N/A 1.000 in N/A 0.190 in N/A 1.130 in N/A 13000 lb N/A 2100 lb
N/A 1.654 in N/A 0.440 in N/A 0.880 in N/A 1.000 in N/A 0.190 in N/A 1.130 in N/A 20000 lb N/A 2100 lb
N/A 2.609 in N/A 0.440 in N/A 0.880 in N/A 1.130 in N/A 0.190 in N/A 1.130 in N/A 13000 lb N/A 2300 lb
N/A 2.609 in N/A 0.440 in N/A 0.910 in N/A 1.060 in N/A 0.160 in N/A 1.130 in N/A 15000 lb N/A 2150 lb
N/A 2.609 in N/A 0.440 in N/A 0.880 in N/A 1.130 in N/A 0.250 in N/A 1.130 in N/A 18000 lb N/A 2500 lb
N/A 3.000 in N/A 0.440 in N/A 1.500 in N/A 1.000 in N/A 0.190 in N/A 1.130 in N/A 13000 lb N/A 2100 lb
N/A 3.000 in N/A 0.500 in N/A 1.500 in N/A 1.250 in N/A 0.250 in N/A 1.250 in N/A 20000 lb N/A 3000 lb
N/A 3.075 in N/A 0.630 in N/A 1.250 in N/A 1.500 in N/A 0.310 in N/A 1.500 in N/A 28000 lb N/A 4600 lb
N/A 3.075 in N/A 0.630 in N/A 1.250 in N/A 1.500 in N/A 0.310 in N/A 1.500 in N/A 48000 lb N/A 4600 lb
N/A 4.000 in N/A 0.440 in N/A 1.500 in N/A 1.000 in N/A 0.190 in N/A 1.130 in N/A 13000 lb N/A 2100 lb
N/A 4.000 in N/A 0.440 in N/A 1.750 in N/A 1.130 in N/A 0.190 in N/A 1.130 in N/A 13000 lb N/A 2100 lb
N/A 4.000 in N/A 0.500 in N/A 1.500 in N/A 0.880 in N/A 0.250 in N/A 1.250 in N/A 19000 lb N/A 2400 lb
N/A 4.000 in N/A 0.500 in N/A 1.750 in N/A 0.880 in N/A 0.250 in N/A 1.250 in N/A 19000 lb N/A 2400 lb
N/A 4.000 in N/A 0.440 in N/A 2.000 in N/A 1.190 in N/A 0.190 in N/A 1.250 in N/A 16500 lb N/A 2400 lb
N/A 4.000 in N/A 0.630 in N/A 2.000 in N/A 1.310 in N/A 0.250 in N/A 1.500 in N/A 22000 lb N/A 3650 lb
N/A 4.000 in N/A 0.630 in N/A 1.750 in N/A 1.310 in N/A 0.310 in N/A 1.500 in N/A 28000 lb N/A 4100 lb
N/A 4.000 in N/A 0.630 in N/A 2.250 in N/A 1.310 in N/A 0.380 in N/A 1.500 in N/A 28000 lb N/A 4500 lb
N/A 4.000 in N/A 0.630 in N/A 2.250 in N/A 2.310 in N/A 0.380 in N/A 1.500 in N/A 28000 lb N/A 4700 lb
N/A 4.040 in N/A 0.630 in N/A 2.000 in N/A 1.310 in N/A 0.310 in N/A 1.500 in N/A 26000 lb N/A 4250 lb
N/A 5.000 in N/A 0.630 in N/A 2.250 in N/A 1.190 in N/A 0.310 in N/A 1.500 in N/A 45000 lb N/A 3,960 lb
N/A 6.000 in N/A 0.440 in N/A 1.500 in N/A 1.000 in N/A 0.190 in N/A 1.130 in N/A 13000 lb N/A 2100 lb
N/A 6.000 in N/A 0.440 in N/A 2.000 in N/A 1.130 in N/A 0.250 in N/A 1.250 in N/A 18000 lb N/A 2500 lb
N/A 6.000 in N/A 0.560 in N/A 2.000 in N/A 1.310 in N/A 0.250 in N/A 1.500 in N/A 21000 lb N/A 3500 lb
N/A 6.000 in N/A 0.560 in N/A 2.500 in N/A 1.310 in N/A 0.250 in N/A 1.500 in N/A 21000 lb N/A 3500 lb
N/A 6.000 in N/A 0.560 in N/A 2.500 in N/A 1.310 in N/A 0.250 in N/A 1.500 in N/A 21000 lb N/A 3500 lb
